FJD Trion AM150A Medium Format Urban Camera
Model: AM150A
A standalone 150MP medium-format aerial camera with an interchangeable FJD lens mount, usable independently or alongside the O1 rig.
Every FJD Trion product is quoted individually to reflect configuration, accessories and support requirements. Tell us about your project and we'll respond with pricing, lead time and (where useful) a demonstration.
Downloads
Datasheets and manuals for this product are being added to the catalogue — request a quote and we'll send the latest documentation directly.
The AM150A packs the same 150MP back-illuminated CMOS sensor used in the O1 payload into a single standalone camera body with an interchangeable FJD lens mount, giving survey teams flexibility to configure oblique or nadir setups without committing to the full five-camera O1 rig. ISO 50-6400, up to 4fps capture and a leaf shutter to 1/2500s make it capable in variable light, and 14-bit RAW output (around 180MB/file) preserves detail for downstream photogrammetry processing. Dual USB-C data ports, trigger/mid-exposure I/O and SSD storage round out an integration-friendly design that also supports combined oblique-imagery-plus-LiDAR workflows. A more accessible entry point than the full O1 rig for teams building a custom aerial mapping payload.
Technical specification
| Resolution | 150MP (14206x10654), back-illuminated CMOS |
|---|---|
| Sensor | 53.4x40mm sensor, 3.76µm pixel size, 4:3 aspect, 83dB dynamic range |
| Exposure | ISO 50-6400; up to 4fps; leaf shutter up to 1/2500s |
| Lens mount | FJD lens mount, interchangeable lenses |
| File format | 14-bit RAW (~180MB/file); IR cut-off filter |
| Data / I/O | 2x USB 3.0 Type-C; trigger/mid-exposure I/O; SSD storage |
|---|
| Weight / dimensions | 610g (excl. lens); 90x93x65mm |
|---|---|
| Power | 12-30V DC |
| Operating environment | -10°C to 40°C; humidity 15-80% non-condensing; API/SDK available |
