FJD Trion S1 3D LiDAR Scanner
Model: S1
A configurable indoor/outdoor SLAM scanner that switches between handheld, backpack, drone and vehicle mounts for large or awkward sites.
Every FJD Trion product is quoted individually to reflect configuration, accessories and support requirements. Tell us about your project and we'll respond with pricing, lead time and (where useful) a demonstration.
Downloads
Datasheets and manuals for this product are being added to the catalogue — request a quote and we'll send the latest documentation directly.
The S1 is built around versatility rather than a single form factor: the same scanner head mounts to a handheld grip, a backpack rig, a drone or a vehicle, so a single unit can cover interiors, large outdoor areas, aerial passes or roadside corridors. Dual hot-swappable batteries give roughly four hours of combined runtime, and FJD quotes around 100m² (roughly 1,000 sq ft) captured in about two minutes of walking. Paired with a V1t RTK rover it produces georeferenced, centimetre-class outdoor point clouds without needing ground control points — a workflow FJD's own case studies show cutting stockpile volume surveys from a full day down to under 20 minutes. A dedicated S1 Pro variant with upgraded hardware also exists, though a full public spec table for it was not available at time of writing — see the gaps note in the accompanying manifest.
Technical specification
| Relative accuracy | ~2 cm (post-processed, experimental conditions) |
|---|
| Runtime | Dual hot-swappable batteries, 4 hours combined runtime |
|---|
| GNSS pairing | Pairs with V1t RTK Rover for georeferenced outdoor scans without ground control points |
|---|
| Capture speed | ~100 m² (~1,000 sq ft) scanned in ~2 minutes |
|---|
| Mount options | Handheld, Backpack, Drone Mount, Car Mount |
|---|
