FJD Trion V10a RTK System
Model: V10a
An AR-enabled RTK rover with dual cameras and a built-in UHF radio, designed to make stakeout visual and intuitive.
Every FJD Trion product is quoted individually to reflect configuration, accessories and support requirements. Tell us about your project and we'll respond with pricing, lead time and (where useful) a demonstration.
Downloads
Datasheets and manuals for this product are being added to the catalogue — request a quote and we'll send the latest documentation directly.
The V10a builds an augmented-reality stakeout workflow directly into the receiver: forward and downward 5MP cameras overlay the target point onto a live camera view, so field staff can walk straight to a stake-out position rather than reading numbers off a screen. It carries a 1408-channel GNSS engine with HAS-PPP support, an integrated 4G modem, Wi-Fi, Bluetooth and a built-in UHF radio rated to 6-12km typical range. IP68-rated and drop-tested from 2m onto a pole, it delivers 8mm+1ppm horizontal / 15mm+1ppm vertical RTK accuracy with tilt compensation up to 60°. A 4,900mAh battery and 30W PD fast charging give roughly 15 hours as a rover or 10 as a base. A strong option for construction and utility teams who want a more intuitive, camera-guided stakeout experience.
Technical specification
| RTK accuracy | H: 8mm+1ppm, V: 15mm+1ppm RMS; init <5s, >99.9% reliability |
|---|---|
| Tilt compensation | 0-60° with RTK tilt compensation (8mm+0.6mm/° tilt) |
| Capacity / runtime | 4,900 mAh; 30W PD fast charge; Rover 15h / Base 10h / Static >25h |
|---|
| Cameras | Forward 5MP / Downward 5MP, 83° FOV, AR stakeout |
|---|
| Radio / network | Integrated 4G modem, Wi-Fi 2.4/5GHz, NFC, BT4.2/BLE, built-in UHF radio (2W, 6-12km typ.) |
|---|
| Channels | 1408-channel multi-GNSS incl. HAS-PPP |
|---|
| Storage | 32 GB |
|---|---|
| IP rating | IP68 (1m immersion); 2m pole-drop rated |
| Size / weight | Φ130 x 68 mm; ~800 g |
| Operating temperature | -35°C to 65°C |
