FJD Trion V1t RTK Rover
Model: V1t
A rugged IP67 GNSS rover with a long-life 6,500mAh battery, built to keep survey crews working a full day without hunting for a charger.
Every FJD Trion product is quoted individually to reflect configuration, accessories and support requirements. Tell us about your project and we'll respond with pricing, lead time and (where useful) a demonstration.
Downloads
Datasheets and manuals for this product are being added to the catalogue — request a quote and we'll send the latest documentation directly.
The V1t is a general-purpose RTK rover built around endurance: IP67 sealing, a 6,500mAh battery good for roughly 20 hours as a rover (10 hours as a base), and 32GB of onboard memory. It delivers horizontal accuracy around 8mm+1ppm and vertical around 15mm+1ppm RMS, with PPP and PPK processing supported for post-mission accuracy improvement. USB-PD 30W fast charging and a 9-32V DC aviation-plug input mean it can run off vehicle power on long site days. A higher-power 5W-radio variant extends correction range at the cost of some battery life. It is also the recommended GNSS partner for FJD's S1 backpack scanner, providing the ground-control-free georeferencing that turns a walk-and-scan capture into a coordinate-accurate deliverable.
Technical specification
| RTK accuracy | H ±(8mm+1ppm), V ±(15mm+1ppm) RMS |
|---|---|
| High-precision static | H: 2.5mm+0.1ppm, V: 3.5mm+0.04ppm |
| Processing modes | PPP and PPK supported |
| Capacity / runtime | 6,500 mAh; Base 10h / Rover 20h (1W radio) |
|---|---|
| Charging | USB PD 30W fast charge; 9-32V DC aviation-plug support |
| Wi-Fi | 802.11 b/g/n |
|---|---|
| 5W radio variant | Base 10h / Rover 15h typical (extended radio range) |
| Constellations | GPS, BDS, GLONASS, Galileo, QZSS, NavIC, SBAS |
|---|
| Size / weight | 162 x 86 mm; 1070 g; IP67 |
|---|---|
| Storage | 32 GB memory |
| Operating temperature | -30°C to 60°C |
